Pipes
ABS coated pipes
- Cost effective
- Durable and flexible
- Rust inhibitor applied to inner surface for extended lifetime cycle
- Variety of colours available; special colours on request
- Available in ESD execution
Stainless steel pipes
- Higher strength to weight ratio than that of coated pipe
- Superior resistance to oil and chemicals
- No burning during cutting
- Environmentally friendly
- Electrostatic discharge, electrically and thermally conductive
Numbering system
eg: CP-2810-IV
Type of the pipe:
CP = ABS coated pipes
SP = ABS coated slide pipes
ECP = ABS coated ESD pipes
ESP = ABS coated ESD slide pipes
SSP = Stainless steel pipes
Diameter and thickness:
2807 = ø28mm × 0,7mm
2810 = ø28mm × 1,0mm
2820 = ø28mm × 2,0mm
Colour code:
WH = White
IV = Ivory
DG = Gray
LB = Light Blue
DB = Blue
GR = Green
BK = Black
.... = Stainless steel
Colours
Colour (Colour code) |
Standard pipe |
Slide pipe |
ESD pipe |
||||
ø28 × 0,7 | ø28 × 1,0 | ø28 × 2,0 | ø28 × 0,7 | ø28 × 1,0 | ø28 × 1,0 | ||
White (WH) | √ | √ | √ | ||||
Ivory (IV) | √ | √ | √ | √ | √ | ||
Gray (DG) | √ | √ | √ | ||||
Light blue (LB) | √ | √ | √ | ||||
Blue (DB) | √ | √ | √ | √ | √ | ||
Green (GR) | √ | √ | √ | √ | √ | ||
Black (BK) | √ | √ | √ | √ | √ | √ | |
Stainleess steel | √ | √ |
Weights
Type |
Part Number |
Dimensions (mm) |
Weight/pc |
|
Standard |
ESD |
|||
ABS coated pipe |
CP-2807-colour code CP-2810-colour code CP-2820-colour code |
ECP-2807-colour code ECP-2810-colour code ECP-2820-colour code |
ø28 × t0,7 × 4000 ø28 × t1,0 × 4000 ø28 × t2,0 × 4000 |
2,050 kg 2,750 kg 4,400 kg |
Slide pipe |
SP-2810-colour code | ESP-2810-colour code | ø28 × t1,0 × 4000 | 3,000 kg |
Stainless steel pipe |
SSP-2807 SSP-2810 |
ø28 × t0,7 × 4000 ø28 × t1,0 × 4000 |
1,800 kg 3,000 kg |
Calculating the lengths of pipes
Horizontal calculating
800 - Length between centres
- 70 - Total length between end of pipe and centre of joint
730 - Practical length to be cut
Vertical calculating
530,0 - Length between end of adjuster and center of joint
- 27,0 - Length between end of pipe and end of adjuster
+16,5 - Length between center and surface of joint
519,5 - Practical length to be cut
